LiFePO4 аккумулятор CALB 5 кВт

 With PV/AV access, thismodule can be used for residential energy storage, commercial operation,emergency rescue, wild exploration, backup power supply and outdoor camping.

More details

AC Input

Voltage (V)

AC 85～265

Nominal Frequency (Hz)

45～65

Input Power (W)

700

Power Factor

≥0.98

Max Efficiency Rate

≥95%

PV Input

Input Voltage (V)

DC 59～100

Max Input Power (W)

1000

Max Input Current (A)

30

Output

AC Output Voltage (V)

220

AC Output Power (VA)

1000

Max Efficiency Rate

≥90%

USB Output (V)

5

Dimensions & Weight

Dimensions (mm)

685×415×490

 ( L×W×H )

Weight (kg)

Around 97

Ambient Condition

Operation Temperature (℃)

0～45

Stock Temperature (℃)

－20～55

Stock Humidity

＜70﹪

Ingress Protection

IP21

Noise (dB)

≤50

Protection

Over Current

Yes

Over Voltage

Yes

Under Voltage

Yes

Over Temperature

Yes

1. Of small size and portable,ideal for the energy source of household & ourdoors

2. Automatically switch between PV and grid inputs

3. Automatically switch on to power-supply the load

4. BMS is used for real-time measurement & detection

5. Status indication by LED

6. Protection against over-current,over-voltage,under-voltage and over-temperature

7. The voltage & temperature of single battery and the current of the module are detected; SOC estimation

8. Long cycle life under the designed working condition

9. Maintenance free
