Аккумулятор LiFePO4 CALB 2,5 кВт
With PV/AV access, this module can be used for residential energy storage, commercial operation, emergency rescue, wild exploration, backup power supply and outdoor camping.
With PV/AV access, this module can be used for residential energy storage, commercial operation, emergency rescue, wild exploration, backup power supply and outdoor camping.
AC Input | |
Voltage (V) | AC 85~265 |
Nominal Frequency (Hz) | 40~65 |
Input Power (W) | 700 |
Max Efficiency Rate | ≥95% |
PV Input | |
Input Voltage (V) | DC 59~100 |
Max Input Power (W) | 1000 |
Max Input Current (A) | 30 |
Output | |
AC Output Voltage (V) | 220 |
AC Output Power (VA) | 1000 |
Max Efficiency Rate | ≥90% |
USB Output (V) | 5 |
Dimensions & Weight | |
Dimensions (mm) | 605×330×445 ( L×W×H ) |
Weight (kg) | Around 58 |
Ambient Condition | |
Operation Temperature (℃) | 0~45 |
Stock Temperature (℃) | -20~55 |
Stock Humidity | <70﹪ |
Ingress Protection | IP21 |
Noise (dB) | ≤50 |
Protection | |
Over Current | Yes |
Over Voltage | Yes |
Under Voltage | Yes |
Over Temperature | Yes |
1. Small, Portable, Suitable for families and outdoor power
2. Automatically Achieves AV and PV Input Function
3. Realizes Switching Function of the Load Supply
4. Use BMS for On-line measurement and real-time monitoring
5. With LED Status Indicators
6. Detection Cells’ Voltage, Temperature, Current and SOC Estimation
7. Long Cycle Life
8. Maintenance-free
