LiFePO4 CABL CAS20
1. CCC certified
2. More than 2000 cycles under the designed working condition
3. High energy density---168WH/KG
4. Ceramic membrane technology applied to enhance safety
5. Highcharge/discharge rates
1. CCC certified
2. More than 2000 cycles under the designed working condition
3. High energy density---168WH/KG
4. Ceramic membrane technology applied to enhance safety
5. Highcharge/discharge rates
Nominal Capacity @ 0.3C | 20Ah |
Nominal Voltage | 3.2 V |
Internal Impedance @ 1 kHz AC | ≤ 2mΩ |
Weight | 0.448kg |
Life Cycle @ 0.3C, 80% DOD | 2,000 |
Maximum Charging Current | 20A |
Maximum Constant Discharging Current | 60A |
Charging Cut-off Voltage | 3.65 V |
Discharging Cut-off Voltage | 2.5 V |
SOC Usage Window | 10% ~ 90% |
Charging Temperature | 0℃ ~ 45℃ |
Discharging Temperature | -20℃ ~ 55℃ |
Storage Temperature within 1 month | -20℃ ~ 45℃ |
Storage Temperature within 1 year | -20℃ ~ 20℃ |
