Контроллер заряда Epsolar MPPT iTracer IT3415 30A
Контроллер заряда EPSOLAR MPPT iTracer IT3415 30A 150V, солнечный контроллер RS232 RS485 с протоколом Modbus, шина CAN 12В 24В 36В 48В автоматическое определение напряжения аккумуляторных батарей.
Контроллер заряда EPSOLAR MPPT iTracer IT3415 30A 150V, солнечный контроллер RS232 RS485 с протоколом Modbus, шина CAN 12В 24В 36В 48В автоматическое определение напряжения аккумуляторных батарей.
Основные характеристики контроллера Epsolar MPPT I-Tracer iT3415ND:
Преимущества:
Model | IT3415ND | IT4415ND | IT6415ND |
Rated system voltage | 12V/24V /36V/48V auto work | ||
Rated battery current | 30A | 45A | 60A |
Rated load current | 30A | 45A | 60A |
Max. PV open circuit voltage | 150V | ||
Voltage range | 8~72V | ||
Max.PV input power | 400W (12V) | 600W (12V) | 800W (12V) |
800W (24V) | 1200W (24V) | 1600W (24V) | |
1200W (36V) | 1800W (36V) | 2400W (36V) | |
1600W (48V) | 2400W (48V) | 3200W (48V) | |
Self-consumption | 1.4~2.2W | ||
Equalize charging voltage | Sealed: 14.6V, Flooded: 14.8V, User-defined: 9~17V | ||
Boost charging voltage | Gel: 14.2V, Sealed: 14.4V, Flooded: 14.6V, User-defined: 9~17V | ||
Float charging voltage | Gel /Sealed /Flooded: 13.8V, User-defined: 9~17V | ||
Low voltage reconnect voltage | Gel /Sealed /Flooded: 12.6V, User-defined: 9~17V | ||
Low voltage disconnect voltage | Gel /Sealed /Flooded: 11.1V, User-defined: 9~17V | ||
Grounding | Common negative | ||
Tracking efficiency | 99% | ||
Peak conversion efficiency | 98% | ||
Dimension | 358x219x102mm | 382x231x107mm | 440x231x110mm |
Terminal | 25mm2 | 35mm2 | 35mm2 |
Net Weight | 3.7kg | 4.6kg | 5.9kg |
Working temperature | -25℃~+55℃ | ||
Storage temperature range | -30℃~+85℃ | ||
Humidity | 95% NC | ||
Enclosure | IP20 |
